MFGF

Hi,

I'm trying to pin down the changes I will need to enable TPMS in my 2009 A6 (facelift) FWD.

I have so far enabled the Hidden Menu in the MMI and turned on the RDK option in main/car/cardevicelist, and set Tires air pressure control to 5 in main/car/carmenuoperation. The bit I am struggling with is coding the ABS module to enable TPMS. I have heard rumours it can be done, but the ABS module has no Long Code Helper for my car, and I can't find any reliable info on which bit(s) to set.

So, my question is - did anyone out there spec TPMS on a 2009 A6 and can check the OE coding of the ABS module for me in VCDS?

Thanks,

MF.

rlarsen

What type of coding do you have??

A Code build on summarized values??

Maybe it is the same as on a A3/TT where you subtract 16384 from the excising value??

• Tire Pressure Monitoring (TPMS):
  • +0000000 = with Tire Pressure Monitoring (PR-7K1/7K6)
  • +0016384 = without Tire Pressure Monitoring (PR-7K0)

You can use this web page: http://obd.netloonies.com/ to see if your current coding value contain the 16384 value.

__________________
With best regards
Rene Larsen

Audi A4 Avant 3.0 TDI quattro tiptronic '09
VCDS 10.6.0 (HEX-USB+CAN)

Hurty

Dear MFGF,
I am also trying to :
see my post : Indirect TPMS enabling with MMI 3G ?
rlarsen kindly tries to support me (thanks again Rene).
Best regards.

__________________
Modifications done :
08/2009 : Valve caps with "Audi" logo
12/2009 : Winter wheels New RS6 18"
02/2010 : Chrome exhaust tail pipes
02/2010 : MMI (3G) activations : hidden menu + APS visual screen + reverse mirror tilt + speed warning + gear recommendation + batt. capacity status bar + needle sweep + "RS6" splashscreen
03/2010 : Front grill with 3 chrome strips
07/2010 : Aux. ventilation activation

New challenges :
MMI : Bord computer + ambiance light + oil level enabling/activation

a6-driver

Hi,

i tried to enable TMPS, too (like A4 8K) but without any succsess. In the german VCDS Board was reported, the A6 4F needs a extra device for TMPS:

Adresse 4C: Reifendruck II Labeldatei: Keine
Teilenummer SW: 4F0 910 274 HW: 4F0 907 274
Bauteil: J793 RKA+ H02 0080
Revision: 00000000 Seriennummer:
Codierung: 0687809
Betriebsnr.: WSC 02324 785 00200

Reifendruckanzeige für Audi A6 Quattro MJ 2009 - Das deutsche VCDS Forum

Regards

rlarsen

But the A6 (4F) facelift doesn't use the wheel sensors any more, so I can't see why they still uses the 4C unit - it should be the same system as the A3/TT and now A4/A5 uses - the ABS/ESP indirect system.

__________________
With best regards
Rene Larsen

Audi A4 Avant 3.0 TDI quattro tiptronic '09
VCDS 10.6.0 (HEX-USB+CAN)

Hurty

Dear all,
Since end of year 2009, on Audi A6 Ambiente 2.0 TDI, the TPMS is not anymore an option, it is now included in serial.
Then I asked to Audi France technical support which TPMS system is it ("direct" with sensors in wheels or "indirect" via ABS-ESP module ?).
Audi answered me yesterday it is "indirect TPMS".
I think this is a very good new ; I am now convinced indeed there is a possibility to enable it on MMI 3G via VAG-COM and/or hidden menu.
Who (C6 owner bought after Nov. 2010) can send me the coding of his module #03-ABS (hardware 4F0 614 517 AT ; software 4F0 910 517 AK) ?
By comparison I hope to manage to identify which bit corresponds to TPMS enabling.

__________________
Modifications done :
08/2009 : Valve caps with "Audi" logo
12/2009 : Winter wheels New RS6 18"
02/2010 : Chrome exhaust tail pipes
02/2010 : MMI (3G) activations : hidden menu + APS visual screen + reverse mirror tilt + speed warning + gear recommendation + batt. capacity status bar + needle sweep + "RS6" splashscreen
03/2010 : Front grill with 3 chrome strips
07/2010 : Aux. ventilation activation

New challenges :
MMI : Bord computer + ambiance light + oil level enabling/activation

MFGF

OK - thanks for this. I've been busy for a few weeks, but just getting round to looking at this now.

My current coding for the ABS module is 0020859 (from a possible maximum of 8388607). Looking at this in binary (Windows calculator is excellent for this), my coding is 00000000101000101111011, which means that my current module does indeed have the bit set that corresponds to 16384 (00000000100000000000000) - the 9th bit in the string.

I am going to try unsetting this by subtracting 16384 from the coding value - leaving me with a coding of 0004475. Here's hoping!!

MF.

MFGF

Ok. Update on this is that the 16384 bit is not the correct one. On my A6, the bit corresponding to 16384 is to enable the Towing Recognition Control Module for a trailer hitch - see image below:



It's frustrating - the bit is in the string somewhere, but which one?

Next option is to email Ross-Tech to see if they can provide more coding information for my ABS module. I will report any progress...

MF.

MFGF

Ross-Tech now have full scan details of my car and are researching the ABS module coding options for me. They inform me that ABS coding is normally done via SVM (Software Version Management) with the dealer scan tool, hence the need for some research.

I will post back if/when I know any more...

MF.

rlarsen

You also need to be sure it is possible to enable TPMS on your ABS/ESP module.

On the B8s (A4/A5) it is only possible to enable TPMS on module with the PR-code: 1AT

The other PR-code available on the B8s are 1AS, but so fare it won't accept the TPMS coding.

It is the same with the Audi Hold Assist (1AT = works, 1AS = doesn't work).

I don't know what the PR-code(s) are for the A6 - but it should be something starting with 1A
